Positive-ratchet floor shifter for the GM 4L60E and other 2, 3 and 4 speed automatics, replacing part number 80842.
If you are building a 4L60E Camaro, an S10 with a hot small-block, a swapped C10 or a street-and-strip car and you want to shift the transmission yourself without overshooting a gear, this floor-mount ratchet shifter replaces part number 80842. It is the shifter people look for when a worn factory console stick no longer lines up with the indicator, when a column shift is being deleted, or when a manual-shifted build keeps missing 2nd and landing in Neutral at the top of a pull.
On a 4L60E the selector lever on the driver side of the case turns the manual shaft, and the manual shaft strokes the manual valve in the valve body. The transmission computer still picks the shift points in Drive, but the manual valve decides which range the computer is allowed to use. A positive ratchet shifter moves that valve one detent per pull. Pull back from Drive and the handle stops in the next range down instead of sliding past it, so a hard upshift into 2nd or 3rd cannot carry on into Neutral. Getting into Reverse or Park takes a deliberate lockout motion, and the 80842 instruction sheet notes the reverse lockout is a one-hand design that meets NHRA and IHRA requirements.
Because the 4L60E has four forward positions (Drive, 3, 2, 1 after Overdrive), the factory 80842 instructions call for removing the three-speed limiter blocker pin and its e-clips on GM four-speeds. Leave that pin in for a TH350, TH400 or other three-speed, and leave it in on a Ford AOD or Chrysler A500/A518, which only have three forward shifter positions.
Keep the 4L60E's real failures separate from shifter problems. A burnt 3-4 clutch pack, a stripped sun shell that leaves you with no 3rd or 4th, or EPC wear causing harsh shifts and P0748 will not be fixed by a new shifter.
Disconnect the cable or rod at the transmission and move the selector lever by hand. You should feel a clean click at every position from Park to 1. If the transmission shifts correctly by hand but not from the cockpit, the shifter or cable is the problem. If it misbehaves either way, work through our 4L60E Camaro shift problems guide or the shift solenoid testing guide first.
Listed coverage is GM TH200, TH250, TH350, TH400, 700R4, 4L60, 4L60E, 4L65E, 4L70E, 4L75E, 4L80E and 4L85E, Ford C4, C5, C6 and AOD, and Chrysler A727, A518, A618, A904, A999 and A500. The bracket is where buyers get caught. Our listing specifies cable bracket 70499 (not included) for a GM 4L60E through 4L85E with a PRNDL switch, while the original 80842 instruction sheet lists kit 75498 for a 4L60E or 4L65E with a PRNDL switch. Check which switch and pan your case has before ordering. Ford AOD takes kit 40496, 4R70W takes 40504, and E4OD or 4R100 takes 40505. If you are unsure, send us the year and VIN or a photo of the left side of the case. Browse every part for this unit on our 4L60E parts page.
If you would rather have a side-grip handle with a cable already in the box, compare the 81120 side-grip ratchet kit.
| Replaces | |
| Type | |
| Speeds | |
| Lever material | |
| Fits | |
| Bracket required | |
| Shipping weight |
Doing this repair right usually means replacing these at the same time. Same transmission, ships together.
Yes. The 4L60E and 4L65E are on the listed coverage. Remove the three-speed limiter blocker pin so the shifter has four forward positions, and check whether your case has a PRNDL switch, because that decides which cable bracket you need.
Our listing calls for cable bracket 70499 on a 4L60E through 4L85E with a PRNDL switch, and the original 80842 sheet lists kit 75498 for the 4L60E and 4L65E. Neither is included. Send us your year and VIN or a photo of the case and we will confirm before you order.
In Drive, yes. The shifter only moves the manual valve. Pull it back one click at a time and you hold lower ranges, which is how people shift manually on the strip.
The neutral safety switch on the shifter or the factory range switch is not seeing Park or Neutral. Recheck the cable adjustment first, then slide the switch until the engine cranks in Park and Neutral only.
No, but it is a good time to check the level and condition. A 4L60E takes Dexron VI. Dark, burnt-smelling fluid means the transmission has its own problem the shifter will not fix.
